Product Overview
AWS E71T-1C is a titania type flux cored wire and designed forall-position welding by single pass & multi pass with CO2 gas shielding. It provides the excellent usability withstable arc, less spattering, good bead appearance, better slag removal, andless quantity of welding fume comparable to solid wire. It provides a goodwelding efficiency thank to high deposition rate particularly. It’s suitable for Butt, fillet welding of mild steel & 490N/mm2 high tensile strength steels of structure such as ships,bridges, buildings and storage tanks etc.
Specifications
Available sizes:
1.2mm, 1.4mm, 1.6 mm, 2.0mm
Typical chemical composition of weld metal(%)
(Shielding Gas: 100% CO2)
C | Mn | Si | P | S |
0.05 | 1.35 | 0.41 | 0.012 | 0.008 |
Typical mechanical properties of weld metal
YP N/mm2(MPa) | TS N/mm2(MPa) | EL % | IV (J) |
0℃ | -20℃ |
480 | 560 | 28 | 109 | 129 |
Size & recommended current range
Dia.mm(in) | 1.2 (0.045”) | 1.4 (0.052”) | 1.6 (0.062”) |
Amp | FLAT, H-FILLET | 120~300 | 150~400 | 180~450 |
V-UP,O.H | 120~260 | 150~270 | 180~280 |
V-DOWN | 200~300 | 200~300 | 250~300 |
HORIZONTAL | 120~280 | 150~320 | 180~350 |
